Zurn Z742-3SP 10″ Light-Duty Top Drain w/ Integral Double Wall Trap, Side Outlet, Backwater Valve

Description

Zurn Z742-3SP 10-1/2″ [267mm] Light-Duty Top Drain w/ Integral Double Wall Trap, 2″ Spigot Side Outlet, Ball Float-Type Backwater Valve

Features & Benefits:

• 3″ [76mm] Spigot Connect Size / Type.
• 10-1/2″ [267mm] Diameter.
• Dura-Coated cast iron body with cast iron, polished bronze, or polished nickel bronze top available.
• Light-Duty.
• Integral double wall trap.
• Side outlet.
• Integral ball float type backwater valve.

Engineering Specification:

• ZURN Z742-3SP 10-1/2″ [267mm] Diameter top drain, Dura-Coated cast iron body with integral double wall trap and side outlet, with ball float type backwater valve, internal bronze cleanout and light-duty loose slotted grate.
• Z742 = D.C.C.I. Body and Top
• ZB742 = D.C.C.I Body w/ Polished Bronze Top
• ZN742 = D.C.C.I Body w/ Polished Nickel Bronze Top
