Tekmar 356 Mixing Control – Variable Speed

Description

Tekmar 356 Mixing Control – Variable Speed.

Features:

• Advanced settings to fine-tune building requirements

• Automatic Boiler Differential

• Boiler Load Reset

• CSA C US certified (approved to applicable UL standards)

• Outdoor Temperature Reset

• Quick setup for easy installation and programming of control

• Test sequence to ensure proper component operation

• User comfort adjustment to increase or decrease building space temperature

• Variable speed pump control

• Warm Weather Shut Down

Specifications:

• Packaged Weight – 1.5lb
• Control – Microprocessor control. This is not a safety (limit) control
• Dimensions – 4-3/4″ H x 2-7/8″ W x 1-7/8″ D (120 x 74 x 48 mm)
• Enclosure – White PVC plastic, NEMA type 1
• Approvals – CSA C US, meets class B: ICES & FCC Part 15
• Ambient Conditions – Indoor use only, 32 to 104°F (0 to 40°C), RH ≤90% Non-condensing
• Power Supply – 24 V (ac) ±10%, 50/60 Hz, 3 VA
• Var. Pump – 120 V (ac) 2.4 A, 1/6 hp
• Relays – 120 V (ac) 5 A, 1/6 hp
• Mixing Demand – 24 V (ac) 2 VA
• Sensor – NTC thermistor, 10 kΩ @ 77°F (25°C ±0.2°C) ß=3892
• Included – Outdoor Sensor 070 and 2 of Universal Sensor 071
• Optional – tekmar type#: 033, 082, 083
• Warranty – Limited 3 Year Warranty
