Description
Franklin Electric 2824055015 Deluxe Control Box – ½ HP, 230V, 60 Hz
The Franklin Electric Deluxe Control Box (CRC Model) offers premium protection and start performance for ½ HP submersible motors. Designed for demanding well systems, it features replaceable components and a rugged enclosure for easy field service.
Features
- For ½ HP, 230V, single-phase 3-wire motors
- Heavy-duty start capacitor and relay for reliable operation
- High-impact weather-resistant housing
- Easy-access design for quick maintenance
Applications
- Residential and light commercial well systems
- Pressure and irrigation pumps
Ratings
|
| Frequency |
60 Hz |
| Phases |
Single-Phase |
| Volts |
230 VAC |
| Control Box Max Amps |
4.3 A |
| Rating |
1/2 hp / .37 kW |
| Control Box Nominal Amps |
3.2 A |
| Hz |
60 Hz |
| Input Phase |
Single-Phase |
| Input Voltage |
230 VAC |
| Control Box Type |
CRC |
Operation
|
| Enclosure Rating |
Type 3R |
| Minimum Operating Temperature |
14 °F |
| Maximum Operating Temperature |
122 °F |
| Storage Temperature |
-13° to 144 °F (-25° to 65 °C) |
