Description

Belimo TFB120-S Damper Actuator, 22 in-lb [2.5 Nm], Spring Return, AC 100… 240 V, On/Off, 1 x SPDT

Technical Specifications:

Actuator Type: Spring Return

Angle of Rotation: 95

Control Type: On/Off

Degree of Protection: IP42, NEMA 2, UL Enclosure Type 2

Direction of Rotation (Fail-Safe): Reversible With cw/ccw Mounting

Electrical Connection: Cable

Power Consumption (Holding): 1.3 W

Power Consumption (Running): 2.5 W

Running Time (Fail-safe): <25 s

Running Time (Motor): 75s

Safety Function: YES

Shaft Diameter: 1/4…1/2″ Round, Centers on 1/2″

Torque: 22 in-lb [2.5 Nm]

Voltage AC/DC: AC 100… 240V

Product & Technical Literature:

• Belimo Technical Data Sheet
• Belimo Installation Instructions
