1/2″ PEX x Sweat (Solder) Brass Ball Valve, Full Port (Lead-Free)

Description

1/2″ PEX x 1/2″ Sweat ball valve. Made from lead-free brass and approved for potable water use.

PEX crimp style outlet (per ASTM F1807 standard), compatible with all types and brands of PEX (A, B, C), including Everhot, Watts, Zurn, Nibco, Viega, etc. Installed using crimp or clamp connection methods.

Note: sweat portion of the valve must be soldered first, followed by the PEX connection.

Features:

• Lead-Free brass body, meets NSF/ANSI 372 & 61-G
• Full port design
• Packing nut
• Teflon (PTFE) seats
• 1/4-turn steel handle
• Meets NSF/ANSI 372
• CSA listed for US and Canada
• cUPC certified

Technical Specifications:

• Inlet: 1/2″ sweat (meets ANSI B16.18)
• Outlet: 1/2″ PEX (per ASTM F1807)
• 600 psi non-shock WOG rated
• 150 psi working pressure
• Max. temperature: 200F
