007 Stainless Steel Circulator Pump w/ IFC, 1/25 HP, 115V

Description

Stainless Steel Taco 007-SF5-IFC Circulator Pump is designed to reduce installation costs when using Taco 007 series stainless steel circulators. It features a built-in IFC (Integral Flow Check) which performa better when compared to a traditional in-line check valve and saves the need for installation of such. Taco 007-SF5-IFC model features a field serviceable cartridge design and provides a quiet, efficient operation and unmatched reliability.

Gaskets (O-rings) included;

Applications:

• Hydronic Heating;
• Radiant Heating;
• Hydro-Air Fan Coils;
• Indirect Water Heaters;
• Chilled Water Cooling;
• Domestic Water Systems;
• And others.

Features:

• Standard High Capacity Output, Compact Design
• Quiet, Efficient Operation
• Direct Drive – Low Power Consumption
• Unique Replaceable Cartridge Design – Field Serviceable
• Self Lubricating
• No Mechanical Seal
• Unmatched Reliability, Maintenance Free
• Universal Flange to Flange Dimensions

Technical Specifications:

• Flow Range: 0 – 23 GPM;
• Head Range: 0 – 10 Feet;
• Minimum Fluid Temperature: 40˚F (4˚C);
• Maximum Fluid Temperature: 230°F (115˚C);
• Maximum Working Pressure: 125 psi;
• Connection Sizes: 3/4″, 1″, 1-1/4″, 1-1/2″ Flanged;
• Voltage: 115V;
• Hertz: 60 Hz;
• Phase 1;
• Amps: 0.76A;
• HP: 1/25HP;

Warranty:
3-year manufacturer’s warranty;
